• Delivers high performance and high throughput to provide maximum flexibility when processing a large number of samples in parallel.
• Full sized model for routine PCR.
• Block temperature range: 4 to 100ºC. Block uniformity at 55ºC: <±0.3ºC.
• Temperature accuracy at 55ºC: <±0.25ºC.
• Fast ramp rate of up to 3.4ºC/second.
• Versatile, fully interchangeable block system allows exchange in a matter of seconds without the need of tools.
• Large 5.7” VGA colour touchscreen.
• Type: 8 peltier element per block.
• Selectable heated lid temperature: 100ºC to 115ºC, or off.
• Heated lid pressure: adjustable, dependent on consumables.
• Easy programming via a color touchscreen and intuitive software.
• Real-time graphical display provides an instant visualization of the program status.
• Stores up to 1000 programs.
• Data transfer: USB port.
• Auto restart on power failure.
• Dimensions (W x D x H): 24 x 42 x 24cm.
• Weight: 9.4 kg.
• Power: 100-230V.
• Warranty: 4 years.
• NOTE: Prime units can be upgraded to achieve gradient capability. The gradient function can be enabled at any time without the need to change a block.


PRIME G is a gradient enabled thermal cycler with all the features of the PRIME base unit plus:
• Wide linear gradient with a range of 30ºC allows annealing temperatures to be optimized in one experiment.
• Gradient calculator function displays the temperature for each of the 8 columns, ensuring easy replication of thermal conditions.
• Gradient can be applied across a temperature range 30 to 80ºC.
• Gradient (max): 30ºC; (min): 1ºC.
