• Designed to meet the needs of water and wastewater laboratories and incorporate advanced features and functions for the ultimate flexibility in operation.
• Offers the accuracy, dependability and ease of use your lab requires. Compact design, intuitive operation and innovative features.
• Over 260 pre-programmed methods for easy and convenient measurements using Orion AQUAfast, Merck, Chemetrics or Hach chemistries. Pre-programmed methods can also be adapted for new chemistries or operators can create their own custom methods.
• Wide variety of vial sizes can be used, including 10mm square vials, 20mm and 50mm rectangular vials and an adjustable round vial holder that accommodates 13mm, 16mm, and 24mm round vials. Each cell holder can be easily installed and replaced in the instrument sample compartment.
• The 3-cell holder includes one adjustable holder for 13mm to 25mm round vials, one holder for 20 or 50mm rectangular vials and one holder for 10mm square vials. The 6-cell holder is ideal for multi-sample measurements in 10mm square vials. With one position reserved for a blank, the 6-cell holder allows the automated analysis of up to 5 samples. The 1-cell holder accommodates a single 10mm square vial.
• AquaMate Test Methods: acid capacity, alkalinity, aluminum, ammonia, ammonium, antimony, AOX, arsenic, BOD, boron, bromine, cadmium, calcium, chloride, chlorine, chlorine dioxide, chromate, chromium, COD, color, copper, cyanide, cyanuric acid, DEHA, detergents, dissolved oxygen, ethanol, fluoride, formaldehyde, gold, hardness, hydrazine, hydrogen peroxide, iodine, iron, lead, magnesium, manganese, mercury, molybdate, molybdenum, monochloramine, nickel, nitrate, nitrite, nitrogen, oxygen, oxygen scavengers, ozone, palladium, pH, phenol, phosphate, platinum, potassium, silica, silver, sodium, sulphate, sulfide, sulfite, surfactants, suspended solids, tin, TOC, volatile organic acids and zinc.
• All pre-programmed methods are stored on the included USB memory stick, allowing operators to load only the methods of interest on their instrument and add or remove methods as needed.
• Allows a one point adjustment on any pre-programmed method to correct for variations in batch reagent chemistries.
• Performance verification tests ensure wavelength accuracy and instrument functionally. In accordance with GLP and GMP, each verification report gives the time, date and instrument serial number.
• Compatible with ink jet and laser printers with HP PCL 5 or greater.
• Built-in wavelength accuracy test is compatible with either the internal lamp or external calibrated standards.
• To validate the instrument performance further, built-in test methods for stray light, noise and resolution are available.
• Photometric measurement modes: absorbance, % transmittance, concentration.
• Graphical with LCD backlight, 9.7 x 7.1cm.
• Sealed membrane keypad with tactile response keys.
• Connectivity: USB type A port for USB stick (front panel), USB type B port for computer (rear panel), USB type A port for printer (rear panel).
• Dimensions (W x D x H): 11.8 x 15.7 x 9.8". Weight: 8.6kg.
• Power: 100 to 240V. cETL approved.
• Warranty: 1 year.

AquaMate 8000 UV-Vis spectrophotometer:

• Delivers unsurpassed data quality by utilizing dual-beam optical geometry and a high-intensity xenon lamp that fires pulses of light only when taking a measurement.
• The light from the xenon lamp is very intense, allowing a beam splitter to extract and measure a small portion of light to an internal reference detector without a loss of performance in sample measurement. This provides simultaneous measurement of the sample with real-time reference beam correction for each flash of the lamp.
• Dual beam optical configuration ensures each measurement is as accurate as possible with reference beam correction on each data point, no drift over long measurements and no peak shift with scan speed changes.
• Xenon lamp provides excellent performance over the entire wavelength range of 190 to 1100nm. It also provides intense light in the UV region of the spectrum adding sensitivity for life science, environmental and organic chemistry applications. It typically provides 5 to 7 years of maintenance-free performance and requires no warm-up. It will not damage sensitive samples since it does not continuously expose samples to intense UV light and ensures sample temperature stability, since it does not change the compartment temperature.
• 1.8nm spectral bandwidth provides optimal system resolution. It permits more light energy to reach the sample resulting in lower detection limits and superior signal-to-noise performance.
• Equipped with enhanced wavelength scanning technology that acquires high quality spectral data quickly. The instrument accelerates through wavelength scans at speeds up to 4,200nm per minute. The exceptionally large photometric range allows accurate measurements of small absorbance changes even when using highly absorbing blank samples. Scan data can be analyzed to determine peak and valley wavelengths and to perform peak height and 3-point net calculations for a sloping baseline.
• Patented out-of-plane monochromator configuration enables maximum performance with a minimum footprint.
• Reference detector ensures the most accurate data is measured from each flash of the lamp.
• Precision silicon detectors allow measurements from the UV to the near-IR.

AquaMate 7000 Vis spectrophotometer:

• Offers similar performance and features as the AquaMate 8000 in a visible-only configuration.
• User interface is easy to use and the 5.0nm spectral bandwidth is ideal for most routine concentration measurements.
• When high resolution is not required to resolve closely spaced peaks, the added energy throughput extends the sensitivity of the analysis and increases the signal-to-noise ratio for dilute samples. Precision electronics and a simple, single-beam optical geometry provides accurate results.
• Tungsten-halogen lamp (typical lifetime 1000 hours).
